The most versatile LoRaWAN Gateway :
Unleash the Power of LoRa with our Multi-Protocol LoRaWAN Gateways
Connect any LoRaWAN sensor. Send data remotely or locally to any network with our open multi-protocol gateway. Our LoRaWAN gateways offer world-class coverage and compatibility.
How does it work?
Access and use data from LoRaWAN devices and other equipment quickly and without coding.
1. Raw LoRaWAN
Our LoRaWAN gateway locally processes raw LoRaWAN frames from IoT devices.
2. Extraction
LoRaWAN Frames are decoded, and the selected data is extracted.
3. Data transfer
Data is sent to an online user interface, where it can be visualised. Our gateway ensures that your messages are safely transmitted.
4. Use of data
The data from LoRaWAN devices can easily be used in a local supervisor or a cloud app. It's more than just a gateway; it's a bridge for your LoRaWAN applications.
LoRaWAN sensors are just a few clicks away!
Connect your LoRaWAN devices in a couple of minutes thanks to a configuration wizard and a growing database of 300+ decoded LoRaWAN devices. Our gateway ensures that you get the most out of your LoRaWAN network.
Technical Characteristics of the LoRa Gateway
Supported protocols
Interface
Software
Hardware
Power Supply
All the following protocols are available simultaneously on the LoRaWAN Gateway :
The Wattsense LoRaWAN gateway operates as an intelligent converter and unifies field communication protocols.Thanks to the LoRaWAN to Bacnet-modbus TCP/IP functionality of our gateways you can easily and quickly modernize your building management system by connecting it to LoRaWAN equipment.
Here is the list of all the interfaces :
Our LoRaWAN gateway is designed to connect all types of equipment in all buildings: IoT sensors including LoRaWAN sensors, meters, heating, air conditioning or air treatment equipment, building management systems (BMS). They are also equipped with Ethernet interfaces to serve multiple applications. The LoRaWAN module compatible with EU, US, Asia
- Secured Linux Yocto distribution.
- Built in drivers for all buses,protocols, and equipment.
- Onboard LoRaWAN server:decodes LoRaWAN data locallydirectly in the hardware.
- Automatic discovery ofequipment on BACnet IP (Scan).
- Remote configuration.
- Secure server communication via MQTT.
- Automatic and secure software updates.
- CPU
528MHz ARM Cortex A7 - Memory
512MB RAM - Storage
4GB eMMC - Consumption
5W - Size
160 x 110 x 55 mm - Weight
350g - 385g - Temperature
from 0°C to +45° - Humidity
From 5% to 95%
No condensation
- 24V DC +/-10%, 2A.
- The cable between the power supply and the Box: 2 wires (red, black), 22 AWG, minimum section: 0.35 mm².
Our LoRaWAN gateways are protected against overvoltage, undervoltage, overcurrent from the power supply with indication by LED: green LED when the power supply is compatible, red LED if it's not suitable.
Our LoRaWAN gateways
Choose the product that better suits your needs.
Wattsense
Bridge
Local product for both on-premises building management and private Cloud LoRaWAN connectivity.
- Live data
- Configuration
- Logs
Solve your connectivity problems
Explore the BridgeWattsense
Tower
A remote product that collects data, creates graphs, sets up alarms, and communicates with the equipment via the Wattsense Cloud server.
- Dashboards
- Graphs
- Live data
- Alarms
- Configuration
- Archives
- Logs
Make sense of your building’s data
Explore the tower
Quick and easy implementation
Dedicated technical support
Over the air updates
Made in France
Applications examples
Frequently asked questions
What is a LoRaWAN gateway ?
A LoRaWAN Gateway is a critical component in a LoRaWAN network that acts as a bridge between LoRaWAN devices and the network server. The gateway receives messages from LoRaWAN sensors and devices operating on various frequency bands and forwards this data to a centralized network server.
How do our LoRaWAN Gateways connect to the internet?
Our LoRaWAN Gateways offer multiple connectivity options for internet access, including Ethernet and 3G/4G modem. This multi-protocol gateway supports Ethernet for a reliable, wired connection. Our LoRaWAN Gateway also comes with built-in cellular capabilities, enabling it to connect to a LoRaWAN cellular network. This feature provides an additional layer of flexibility, particularly for applications where traditional internet connectivity options may be limited.
Coverage & connectivity
Our gateways offer extensive coverage, ensuring that messages from all corners of your building get through. The LoRaWAN wireless protocol guarantees a reliable connection, no matter the size of your network.
What type of buildings and systems can benefit from using the Wattsense LoRaWAN Gateway?
Wattsense's LoRaWAN Gateway is versatile and can be deployed in various types of buildings, including commercial spaces, hospitals, schools, and multi-housing properties. These gateways are ideal to improve systems management related to heating, ventilation, air conditioning, energy efficiency, and other building management systems (BMS).
Discover our use cases hereWhat Kind of LoRaWAN Devices Are Compatible with the Wattsense LoRa Gateways?
Our Wattsense LoRa gateways are designed to be highly versatile and compatible with every LoRaWAN devices. This includes various types of sensors LoRaWAN, actuators, and other IoT devices. Whether you're looking to monitor temperature, energy usage, or air quality, our gateways are engineered to seamlessly integrate these devices into private LoRaWAN networks. The Wattsense product range includes bridge LoRaWAN solutions that enable easy and secure communication between your devices and systems, enhancing the overall performance of your IoT ecosystem. We've already decoded the frames of over 300 LoRaWAN devices, and this is just the beginning! We can decode your LoRaWAN equipment for free, so you can easily integrate them with our solution.
Check the list of decoded equipmentWhat is the Cost of a LoRaWAN Gateway?
You can find information on the different plans and licences on the product pages for the Wattsense Tower and the Wattsense Bridge.
For a more detailed quote tailored to your specific needs, we encourage you to contact our sales team. They can provide you with a customized cost estimate, helping you make an informed decision that aligns with your budget and technical requirements.
Contact usDo you want to add more value to your building with LoRaWAN ?
